1999 TRUMPF Trumatic 500R
SOLD
Specifications
| Manufacturer | TRUMPF |
| Model | Trumatic 500R |
| Year | 1999 |
| Condition | Used |
| CNC control | Trumagraph CC220S |
| Max working area | 2500 x 1300 mm |
| Max workpiece weight | 150 kg |
| Required space | 6900 x 5800 mm |
| Max stroke frequency | 900 1/min |
| Max sheet thickness | 8 mm |
| Max punching force | 220 kN |
| Number of tool positions | 20 |
| Max punch diameter | 76.2 mm |
| Weight of the machine | approx. 11050 kg |
| Height of the machine | 2200 mm |
| Working hours | 13960h |
Description
Trumpf punching machine in good condition.
Can be inspected under power.
Immediately available.
Very large set of tooling included.
